PL1042

PL1042 | Suspended Cube LED Downlight for Architectural Interiors

The PL1042 is a suspended LED downlight with a modern cubic profile, designed to bring clean geometry and focused illumination to contemporary spaces. Suspended from the ceiling by discreet cable mounts, it provides efficient, glare-free lighting in a minimal and compact format.

🧊 Key Features:

• Cubic Pendant Design: Clean architectural form with a square footprint — ideal for minimal interiors
• Suspended Mounting: Ceiling-mounted via cable suspension for floating effect
• Opal Diffuser: Delivers soft, even downward light without glare
• Compact Power: Small size, strong performance — ideal for focused zones or grouped installations
• Driver Options: Available with ON/OFF or DALI for integration with control systems
• Customisable Appearance: White or black finishes as standard; custom RAL available for full design flexibility

🏢 Ideal Applications:
Reception areas, meeting rooms, hospitality zones, retail settings, creative studios, and high-end residential projects seeking discrete, modern downlighting with a sculptural form

📐 Technical Specifications:

• Power Consumption: 15 W, 18 W, 25 W, 29 W
• Luminous Flux: 1,580 lm, 1,890 lm, 2,540 lm, 3,080 lm
• Luminous Efficacy: Up to 111 lm/W
• Colour Temperature: 3000 K or 4000 K
• CRI: >80
• UGR: <19
• Driver Options: ON/OFF, DALI
• Mounting Type: Suspended (cable suspension)
• Protection Rating: IP20
• Impact Resistance: IK03
• Class of Protection: Class I
• Housing Material: Powder-coated steel
• Diffuser: Opal
• Dimensions (L x W x H): 300 mm x 300 mm, 400 mm x 400 mm, 600 mm x 600 mm | H: 58 mm
• Finish Options: White (RAL 9003), Black (RAL 9005), custom RAL on request

Why Choose PL1042?
Because good lighting isn’t just about output — it’s about form. The PL1042 brings architectural precision and lighting performance together in one bold, cubic silhouette.

DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.
