PL1042

PL1042

PENDANT

This decorative bracket is specifically designed for use with LED light sources, offering a stylish and functional solution for your lighting needs. Perfect for providing ambient lighting, it combines practicality with contemporary design.

  • Materials:
  • Installation:

PL1042 | Suspended Cube LED Downlight for Architectural Interiors

The PL1042 is a suspended LED downlight with a modern cubic profile, designed to bring clean geometry and focused illumination to contemporary spaces. Suspended from the ceiling by discreet cable mounts, it provides efficient, glare-free lighting in a minimal and compact format.

🧊 Key Features:

  • Cubic Pendant Design: Clean architectural form with a square footprint — ideal for minimal interiors
  • Suspended Mounting: Ceiling-mounted via cable suspension for floating effect
  • Opal Diffuser: Delivers soft, even downward light without glare
  • Compact Power: Small size, strong performance — ideal for focused zones or grouped installations
  • Driver Options: Available with ON/OFF or DALI for integration with control systems
  • Customisable Appearance: White or black finishes as standard; custom RAL available for full design flexibility

🏢 Ideal Applications:
Reception areas, meeting rooms, hospitality zones, retail settings, creative studios, and high-end residential projects seeking discrete, modern downlighting with a sculptural form

📐 Technical Specifications:

  • Power Consumption: 15 W, 18 W, 25 W, 29 W
  • Luminous Flux: 1,580 lm, 1,890 lm, 2,540 lm, 3,080 lm
  • Luminous Efficacy: Up to 111 lm/W
  • Colour Temperature: 3000 K or 4000 K
  • CRI: >80
  • UGR: <19
  • Driver Options: ON/OFF, DALI
  • Mounting Type: Suspended (cable suspension)
  • Protection Rating: IP20
  • Impact Resistance: IK03
  • Class of Protection: Class I
  • Housing Material: Powder-coated steel
  • Diffuser: Opal
  • Dimensions (L x W x H): 300 mm x 300 mm, 400 mm x 400 mm, 600 mm x 600 mm | H: 58 mm
  • Finish Options: White (RAL 9003), Black (RAL 9005), custom RAL on request

Why Choose PL1042?
Because good lighting isn’t just about output — it’s about form. The PL1042 brings architectural precision and lighting performance together in one bold, cubic silhouette.

DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.

WATTAGE LUMEN LENGTH (L) WIDTH (W) HEIGHT (H)
14

1650 llm

85 85 200
20

2310 llm

85 85 200
27

3090 llm

85 85 200
