TS1020 | Linear LED Luminaire for 3-Circuit Track Systems

TS1020 is a high-efficiency linear LED profile designed for direct mounting onto 3-circuit electrical track systems. Featuring integrated track adapters, clean optics, and architectural styling, this profile delivers professional-grade illumination without the need for hardwiring — ideal for modular, reconfigurable commercial spaces.

🧩 Key Features:

• Track-Integrated Design: Supplied with built-in adapters for seamless connection to 3-circuit tracks
• Modular Lengths: Available in 545 mm, 1085 mm, and 1625 mm formats for flexible planning
• Performance Output: Up to 4,990 lm from 13–45 W, delivering up to 125 lm/W
• Optical Options: Microprismatic (MPRM), Opal, or Parabolic Louvre (PAR) for glare management and diffusion
• Driver Options: ON/OFF or DALI control
• Glare Control: UGR ratings as low as 18, suitable for office and educational environments
• Finish Customisation: Available in white, grey, black — or full RAL custom colours
• Important Note: Designed as standalone fixtures — not suitable for continuous line installations

🏢 Ideal Applications:

Corporate offices, reception zones, conference rooms, commercial interiors, and learning environments where lighting flexibility and fast installation are essential.

📐 Technical Specifications:

• Mounting Type: 3-circuit track-mounted
• Form: Linear profile with built-in track connector
• Length Options: 545 mm, 1085 mm, 1625 mm
• Power Range: 13 – 45 W
• Luminous Flux: 960 – 4,990 lm
• Luminous Efficacy: 74 – 125 lm/W
• UGR: 18, 19, 22
• Driver Options: ON/OFF, DALI
• Diffuser Options: MPRM, OPAL, PAR
• CRI: >80 or >90 (830, 840, 930, 940, 8TW)
• Colour Temperature: 2700 – 6500 K
• MacAdam Step: SDCM 3
• Housing Material: Powder-coated aluminium
• Finish Options: White, Grey, Black, or custom RAL
• Protection Rating: IP40
• Impact Resistance: IK03, IK04
• Class of Protection: Class I
• Net Weight: 1.6 – 4.0 kg
• Operating Temperature: -15 to +40°C
• Power Factor: 0.96
• Emergency Module: Optional
• Motion Sensor: Optional
• Flicker: ≤3%
• Lifespan: 100,000 h (L80B10), 64,000 h (L90B10)
• Certifications: CE, HACCP+

Why Specify TS1020?

Because track lighting should offer more than just flexibility — TS1020 delivers clean lines, controlled output, and no-nonsense installation, all in a single architectural-ready solution.

DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.
