AR1007

AR1007

ARCHITECTURAL

A family of circular LED luminaires with a modern and versatile design, suitable for any interior space. Their key features include uniform luminance across the OPAL diffuser and high-quality lighting performance. Suspensions included in the set.

  • Materials: Powder painted aluminum profile (white, grey, black colours in standard). OPAL diffuser.
  • Installation:


AR1007 | Architectural LED Ring Feature Pendant

The is a AR1007 suspended LED luminaire featuring a circular design. Its modern form and uniform illumination make it an ideal choice for adding a contemporary architectural statement to interior spaces.

🔍 Key Features:

Architectural Design: Circular shape crafted from powder-coated aluminium, offering a sleek and modern aesthetic.

Uniform Illumination: Equipped with an opal diffuser that ensures even light distribution, enhancing visual comfort.

Efficient Performance: Delivers a luminous flux of up to 14,000 lumens with an efficacy of up to 100 lm/W, providing bright and energy-efficient lighting.

Customisable Finish: Available in standard white, grey, or black finishes, with the option for custom RAL colours to match specific design requirements.

Suspended Installation: Designed for pendant mounting, supplied with a suspension kit for flexible installation heights.

Control Options: Available with ON/OFF or DALI drivers. Optional motion sensor and emergency module integrations.

🏢 Ideal Applications:

Perfect for offices, conference rooms, receptions, commercial spaces, corridors, and staircases where modern design and efficient lighting are essential.

📐 Technical Specifications:

  • Light Source: Integrated LED

  • Power Consumption: 38–140W

  • Luminous Flux: 3,740–14,000 lm

  • Luminous Efficacy: Up to 100 lm/W

  • Colour Temperature: 3000K or 4000K

  • CRI: 80 or 90

  • MacAdam SDCM: 3​

  • UGR: ≤19​

  • Driver Options: ON/OFF, DALI

  • Emergency Module: Optional

  • Motion Sensor: Optional

  • Protection Rating: IP40​

  • Impact Resistance: IK04​

  • Class of Protection: Class I

  • Housing Material: Powder-coated aluminium

  • Diffuser Material: Opal/matt plastic

  • Dimensions: Outer Diameter: 800 mm or 1200 mm

  • Weight: 6.8–10.5 kg

The AR1007 combines modern design with high-performance lighting, making it a versatile choice for enhancing contemporary interiors with both style and functionality.


DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.

WATTAGE llm/W DIAMETER (Ø) HEIGHT (H)
38
4,745 llm
640 62
50
6,325 llm
820 62
63
7,900 llm
1000 62



CONTINUE TO CUSTOMISE
  • Energy Efficiency

    We are commited to utilising the most energy-efficient lighting solutions on the market. Sustainable choices for your business or private use.

  • Long Life Electronics

    Recent advancements make the switch to LED a long-lasting investment. Embrace the durability and energy-saving features for an eco-friendly choice.

  • Certified Quality System

    Manufactured and audited to ISO9001:2015 by TÜV SÜD Rheinland.
