INDUSTRIAL

An industrial lighting line featuring a fast-linkage system for efficient installation. Please note that the standard version does not include through wiring. This design allows for quick assembly while ensuring reliable performance, making it suitable for various industrial applications.

  • Materials: Housing made of electrostatically painted aluminum (standard color: white), transparent diffuser made of PMMA. Optical system 60°, 90°, SYM, ASYM. Smooth adjustment of fasteners spacing (values in the table apply variants with upper masking cover IP40)
  • Installation:

ID1017 | Slim Industrial LED Batten for Efficient Linear Installations

The ID1017 is a slimline industrial LED batten engineered for efficient linear lighting installations. Combining durable construction with high luminous efficacy

it’s designed to perform reliably across commercial, retail, and light industrial environments.​


🔍 Key Features:

Slim Profile: Compact, minimalist design ensures easy integration in both open and constrained spaces.​

High Luminous Efficiency: Offers up to 150 lm/W, delivering bright, uniform light while minimizing energy consumption.​

Durable Construction: Features a robust steel body with a white powder-coated finish, providing longevity and resistance to environmental factors.​

Flexible Mounting: Suitable for surface or suspended installation, with tool-free access for fast, efficient installation.​

Control Options: Available with ON/OFF and DALI dimmable driver options for advanced lighting control systems.​

Certified Quality: Compliant with CE standards, ensuring safe, dependable performance across diverse applications.​



🏭 Ideal Applications: ID1017

Retail environments

Commercial service spaces

Workshops and production areas

Storage and logistics zones​


📐 Technical Specifications:

Power Consumption: 17W / 34W / 51W (depending on configuration)​

Luminous Flux: 2,550 lm / 5,100 lm / 7,650 lm​

Luminous Efficacy: Up to 150 lm/W​

Colour Temperature: 4000K (Neutral White)​

CRI: >80​

MacAdam SDCM: 3​

UGR: <25 (depending on installation height)​

Driver Options: ON/OFF, DALI​

Emergency Module: Optional (available with 3h emergency pack)​

Protection Rating: IP20​

Impact Resistance: IK04​

Class of Protection: Class I​

Housing Material: Steel (powder-coated white)​

Diffuser Material: Polycarbonate (opal)​

Mounting Options: Surface-mounted or suspended​

Dimensions: 590mm / 1170mm / 1450mm length options​

Weight: 1.5–2.8 kg (depending on version)​

DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.

WATTAGE llm/W LENGTH (L) WIDTH (W) HEIGHT (H)
22
3,300 llm
 1150 58 47
32
4,950 llm
 1722 58 47
51
8,250 llm
 2870 58 47
60
9,900 llm
 3443 58 47
CONTINUE TO CUSTOMISE

KEY HIGHLIGHTS

  • Energy Efficiency

    We are commited to utilising the most energy-efficient lighting solutions on the market. Sustainable choices for your business or private use.

  • Long Life Electronics

    Recent advancements make the switch to LED a long-lasting investment. Embrace the durability and energy-saving features for an eco-friendly choice.

  • Certified Quality System

    Manufactured and audited to ISO9001:2015 by TÜV SÜD Rheinland.
