An industrial lighting line equipped with a fast-linkage system for quick and efficient installation. This design simplifies the setup process, making it ideal for various industrial applications while ensuring reliable performance and versatility.
Materials: Housing made of electrostatically painted stainless steel (standard color: white). Optical system SYM 60ยฐ, SYM 90ยฐ, RETAIL ASYM. Adjustment of fasteners spacing. Invisible linear joint in set. Through wiring TH5 in set (in luminaires and empty modules).
Installation:
Link to this
ID1019 | Square Profile Industrial LED Batten for Modular Linear Systems
The ID1019 is a square-profile LED batten designed for efficient, modular linear lighting installations.
Engineered with durability and flexibility in mind, it is ideal for commercial, retail, and industrial applications demanding continuous, high-quality illumination.
๐ Key Features:
Square Profile Design: Modern, geometric housing provides a clean, uniform aesthetic across installations.โ
High Luminous Efficiency: Offers up to 150 lm/W, maximizing energy savings while delivering consistent, bright output.โ
Durable Build Quality: Manufactured with a powder-coated steel body and opal polycarbonate diffuser for enhanced longevity and impact resistance.โ
Modular Flexibility: Can be installed as single fittings or joined together to create continuous lighting lines with consistent light flow.โ
Control Options: Available with ON/OFF and DALI dimming drivers; optional emergency modules enhance safety compliance.โ
Certified Quality: CE-compliant, ensuring dependable, safe operation for demanding environments.โ
๐ญ Ideal Applications:
Retail chains and supermarkets
Production facilities and workshops
Warehouses and logistics centers
Commercial service spacesโ
๐ ID1019 Technical Specifications:
Power Consumption: 17W / 34W / 51W (depending on model)โ
Luminous Flux: 2,550 lm / 5,100 lm / 7,650 lmโ
Luminous Efficacy: Up to 150 lm/Wโ
Colour Temperature: 4000K (Neutral White)โ
CRI: >80โ
MacAdam SDCM: 3โ
UGR: <25 (dependent on installation and optics)โ
Driver Options: ON/OFF, DALIโ
Emergency Module: Optional (available with 1h emergency backup)โ
Protection Rating: IP20โ
Impact Resistance: IK04โ
Class of Protection: Class Iโ
Housing Material: Steel (powder-coated white)โ
Diffuser Material: Polycarbonate (opal)โ
Mounting Options: Surface-mounted or suspended; accessories available for modular linear connectionsโ
Weight: ~1.5โ2.8 kg (depending on configuration)โ
DIMENSIONS
NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.
