LS1020

LS1020

LIGHTING SYSTEMS

This new recessed LED luminaires system is designed to create seamless lighting lines without visible connections or mechanical mounting elements. It features flexible extruded diffusers, allowing for a smooth and elegant design. This sophisticated solution is highly effective for illuminating offices, conference rooms, reception areas, and other prestigious spaces. By combining aesthetics with functionality, it ensures a refined lighting experience that enhances the ambiance of any professional environment while providing optimal illumination.

  • Materials: Electrostatically painted trimless aluminum profile (standard colours: white, grey, black), OPAL diffuser made of PMMA or microprismatic diffuser MPRM
  • Installation:

LS1020 | Recessed Trimless Linear LED System for Plasterboard Ceilings

LS1020 is a fully recessed linear LED lighting system designed to disappear into plasterboard ceilings with no visible trim, fixings, or joints. Built for continuous line installations, it delivers seamless light with a clean ceiling aesthetic. Perfect for premium offices and design-led commercial spaces, the system also supports optional DALI control and emergency integration.

🧩 Key Features:

  • Trimless Recessed Profile: Ultra-clean integration into plasterboard ceilings with no exposed borders or clips
  • Modular Inline Design: Enables seamless, uninterrupted light lines using invisible joints
  • Premium Optical Options: Choose between opal, microprismatic, or advanced low-glare diffusers
  • Wide Lumen & Power Range: 1,240 – 6,430 lm from 13 – 48 W
  • Driver Options: Available in ON/OFF or DALI for smart building integration
  • Long Life: Rated up to 100,000 hours (L80B10) — built for longevity in demanding applications
  • Accessories Included: End caps, joining kits, corner templates, and mounting brackets

🏢 Ideal Applications:

High-end offices, reception areas, conference rooms, corridors, classrooms, lecture theatres, and modern commercial interiors demanding clean ceiling finishes and uninterrupted lighting

📐 Technical Specifications:

  • Mounting Type: Recessed (plasterboard)
  • Power Consumption: 13 – 48 W
  • Luminous Flux: 1,240 – 6,430 lm
  • Luminous Efficacy: 95 – 134 lm/W
  • Colour Temperatures: 2700 K, 3000 K, 4000 K, or tunable white (2700–6500 K)
  • CRI: >80 or >90 (830, 840, 930, 940, 8TW)
  • UGR: 22
  • Driver Options: ON/OFF, DALI
  • Optics: Opal diffuser, Microprismatic (MPRM), MPOP
  • Beam Type: Medium distribution
  • Protection Rating: IP20
  • Impact Resistance: IK04
  • Class of Protection: Class I
  • MacAdam Step: SDCM 3
  • Finish Options: White, Black, Grey
  • Certifications: CE, HACCP+, EAC
  • Lifespan: 100,000 h (L80B10), 64,000 h (L90B10)
  • Accessories: End caps, trimless joining sets, recessed brackets, corner templates

Why Specify LS1020?

Because when the ceiling must be pristine and performance uncompromised, LS1020 delivers — invisible mount, continuous light, and premium optics for tomorrow’s interior architecture.

DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.

WATTAGE LUMEN LENGTH (L) WIDTH (W) HEIGHT (H)
13

1,480 llm

 545 57 78
25

2,955 llm

 1,085 57 78
36

4,425 llm

 1,625 57 78
48

5,900 llm

 2,170 57 78
CONTINUE TO CUSTOMISE

KEY HIGHLIGHTS

  • Energy Efficiency

    We are commited to utilising the most energy-efficient lighting solutions on the market. Sustainable choices for your business or private use.

  • Long Life Electronics

    Recent advancements make the switch to LED a long-lasting investment. Embrace the durability and energy-saving features for an eco-friendly choice.

  • Certified Quality System

    Manufactured and audited to ISO9001:2015 by TÜV SÜD Rheinland.
