PL1031

PL1031 | Suspended Modular-Style LED Luminaire for Contemporary Commercial Interiors

The PL1031 is a pendant-mounted modular-style LED luminaire designed for suspended ceiling applications.

Combining high luminous efficacy with low-glare illumination, it provides a clean, modern lighting solution ideal for commercial and public environments where architectural aesthetics and visual comfort are essential.

🔍 Key Features:

Suspended Modular Design: Suspended installation via wire kits, creating a clean, floating ceiling aesthetic perfect for modern architectural spaces.​

High Luminous Efficacy: Achieves up to 125 lm/W, offering energy-efficient brightness with reduced operational costs.​

Low Glare Comfort: Designed with a high-quality opal PMMA diffuser to ensure comfortable, glare-controlled illumination.​

Durable Construction: Powder-coated steel body and robust diffuser for long-term, consistent lighting performance.​

Flexible Control Options: Available with ON/OFF or DALI dimmable drivers; optional emergency module available for added resilience and safety.​

Certified Quality: CE-compliant for guaranteed performance, safety, and compliance with modern project standards.​

🏢 Ideal Applications:

Offices and conference areas

Educational institutions

Retail stores and boutiques

Healthcare facilities

Hotel lobbies and hospitality interiors

Public sector and civic buildings​

📐 Technical Specifications:

Power Consumption: 34W​

Luminous Flux: 4,250 lm​

Luminous Efficacy: Up to 125 lm/W​

Colour Temperature: 3000K or 4000K​

CRI: >80​

MacAdam SDCM: 3​

UGR: <19 (depending on suspension height and room configuration)​

Driver Options: ON/OFF, DALI​

Emergency Module: Optional (1h emergency backup available)​

Protection Rating: IP40​

Impact Resistance: IK04​

Class of Protection: Class I​

Housing Material: Steel (powder-coated)​

Diffuser Material: PMMA (opal)​

Mounting Options: Suspended from ceiling using adjustable wire suspension kit​

Dimensions: 595mm x 595mm​

Weight: ~3.5 kg​

⚡ Quick takeaway:

The PL1031 offers modern, floating modular lighting — delivering low-glare comfort and architectural elegance where traditional surface or recessed solutions fall short.

Perfect for elevating interiors with a minimalist yet powerful lighting presence. 🎯

DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.
