SUSPENDED

This modern louver luminaire is designed for LED light sources, showcasing high technical and optical performance. It features aluminum parabolic louvers, which ensure a very low glare rate, enhancing visual comfort. Additionally, it boasts low power consumption compared to traditional light sources, making it an energy-efficient choice. The innovative optical system is particularly well-suited for illuminating office spaces, especially for computer work, providing optimal lighting conditions. Furthermore, the luminaire offers the option to include the "Active+" self-learning energy-saving system. This out-of-the-box solution integrates an LED driver and a small sensor built into the luminaire, making it ideal for refurbishment projects as well as new offices, corridors, and open-plan areas.

  • Materials: White housing made of electrostatically painted steel, parabolic louver made of anodized, polished aluminum of high purity, LED module with additional microprismatic diffuser. Standard version for suspended ceilings has accessories, which make montage of suspensions possible.
  • Installation:

SC1011 | Recessed Lay-In Parabolic LED Luminaire for Grid Ceiling Systems

The SC1011 is a recessed lay-in modular LED luminaire, built for environments demanding precise glare control and high visual comfort.

Featuring advanced parabolic optics, it offers energy-efficient, low-glare illumination ideally suited to professional and educational interiors.

🔍 Key Features:

  • Parabolic Reflector Optics: Engineered with precision reflective elements for optimal light control and significantly reduced glare.​
  • Lay-In Grid Compatibility: Designed for easy, rapid drop-in installation into 600x600mm or 625x625mm modular T-bar ceiling grids.​
  • High Luminous Efficacy: Delivers up to 120 lm/W, ensuring strong, energy-efficient illumination with reduced operational costs.​
  • Durable Construction: Robust steel housing with a powder-coated finish and precision parabolic optics ensures long-term, consistent performance.​
  • Flexible Control Options: Available with ON/OFF or DALI dimmable drivers; optional emergency backup module available for safety-critical installations.​
  • Certified Quality: SC1011 CE and ENEC 28 certified, guaranteeing top-tier European compliance for safety, quality, and performance.

🏢 Ideal Applications:

  • Corporate offices and conference rooms
  • Educational facilities and lecture halls
  • Healthcare institutions and clinical areas
  • Public administration buildings
  • Retail showrooms and commercial interiors​

📐 Technical Specifications:

  • Power Consumption: 34W​
  • Luminous Flux: 4,100 lm​
  • Luminous Efficacy: Up to 120 lm/W​
  • Colour Temperature: 3000K or 4000K​
  • CRI: >80​
  • MacAdam SDCM: 3​
  • UGR: <19 (depending on installation height and grid layout)​
  • Driver Options: ON/OFF, DALI​
  • Emergency Module: Optional (1h emergency backup available)​
  • Protection Rating: IP40 (below ceiling), IP20 (above ceiling)​
  • Impact Resistance: IK04​
  • Class of Protection: Class I​
  • Housing Material: Steel (powder-coated)​
  • Optics Type: Parabolic reflectors for maximum glare control​
  • Mounting Options: Recessed lay-in installation into 600x600mm or 625x625mm modular ceilings​
  • Dimensions: 595mm x 595mm / 620mm x 620mm options​
  • Weight: ~3.5 kg​

⚡ Quick takeaway:

  • The SC1011 is your classic low-glare office lighting solution — combining energy efficiency, rapid modular ceiling installation, and the trusted performance of ENEC 28 Certification.
  • Perfect when you need maximum comfort with minimum ceiling disruption. 🎯

DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.

WATTAGE LUMEN LENGTH (L) WIDTH (W) HEIGHT (H)
19

3,002 llm

 595 595 45
2-Cell
24

3,792 llm

 595 595 45
2-Cell
27

4,266 llm

 595 595 45
2-Cell
30

4,440 llm

 595 595 45
3-Cell
36

5,688 llm

 595 595 45
3-Cell
42

6,636 llm

 595 595 45
3-Cell
CONTINUE TO CUSTOMISE

KEY HIGHLIGHTS

  • Energy Efficiency

    We are commited to utilising the most energy-efficient lighting solutions on the market. Sustainable choices for your business or private use.

  • Long Life Electronics

    Recent advancements make the switch to LED a long-lasting investment. Embrace the durability and energy-saving features for an eco-friendly choice.

  • Certified Quality System

    Manufactured and audited to ISO9001:2015 by TÜV SÜD Rheinland.
