SD1016

SD1016 | IP65 Surface-Mounted Tubular LED Downlight for Wet Zones

The SD1016 is an IP65-rated ceiling-mounted tubular LED downlight, designed to deliver directional lighting in moisture-prone environments. With its clean architectural form, selectable beam angles, and sealed aluminium construction, it offers robust performance in bathrooms, changing rooms, and sheltered outdoor spaces — all without compromising aesthetics.

🚿 Key Features:

• IP65 Protection: Fully sealed against dust and water — ideal for wet rooms and covered outdoor ceilings
• Beam Control Options: Choose from 30°, 50°, or 70° beam angles for focused, medium, or wide light distribution
• Robust Housing: IK10 impact resistance and powder-coated aluminium body — built for public and high-traffic spaces
• Driver Options: ON/OFF and DALI-compatible for flexible integration
• Custom Finishes: Anthracite, black, white, grey as standard — custom RAL colours available on request
• Optional Modules: Emergency function and motion sensor available

🏢 Ideal Applications:

Bathrooms, changing rooms, wellness centres, sports facilities, hotel wet zones, exterior soffits, or any space requiring a stylish, water-resistant downlight

📐 Technical Specifications:

• Power Consumption: 15 W, 21 W, 29 W
• Luminous Flux: 1,330 – 2,640 lm
• Beam Angles: 30°, 50°, 70°
• Luminous Efficacy: 82 – 98 lm/W
• Colour Temperature: 3000 K, 4000 K
• CRI: >80 (830, 840)
• UGR: 18–27
• Driver Options: ON/OFF, DALI
• Mounting Type: Surface-mounted (ceiling)
• Protection Rating: IP65
• Impact Resistance: IK10
• Class of Protection: Class I
• Housing Material: Powder-coated aluminium
• Diffuser: Transparent
• Finish Options: Anthracite, White (RAL 9003), Black (RAL 9005), Grey, custom RAL
• Operating Temp Range: -20°C to +35°C
• Certifications: CE, HACCP+

Why Specify SD1016?

Because great lighting doesn’t stop at dry zones. SD1016 gives you beam control, rugged protection, and a clean design language — wherever moisture or durability is non-negotiable.

DIMENSIONS
