SD1018

SD1018 | Minimalist Surface-Mounted LED Downlight with IP44 Protection

SD1018 is a compact architectural LED luminaire designed for surface or wall mounting. With a crisp geometric form and a clean opal diffuser, it delivers soft, wide-beam illumination that’s ideal for corridors, stairwells, and transitional spaces. A reliable, no-fuss solution for subtle yet effective lighting in high-traffic zones.

🧩 Key Features:

• Low-Profile Housing: Clean, minimal form suited for ceiling or wall installations
• IP44 Protection: Suitable for damp or semi-outdoor environments such as arcades or stairwells
• Efficient Output: 600 lm from 12 W power draw with wide beam distribution
• On/Off Simplicity: Includes integrated non-dimmable LED driver
• Visual Comfort: Structural opal diffuser ensures even illumination with UGR 21
• Finish Options: Available in white, grey, black, or anthracite — or custom RAL on request
• Durable Build: Powder-coated steel housing with opalised plastic diffuser

🏢 Ideal Applications:

Corridors, staircases, arcades, technical areas, lift lobbies, and service entrances requiring robust, glare-controlled surface lighting.

📐 Technical Specifications:

• Mounting Type: Ceiling or wall surface-mounted
• Form Factor: Minimalist architectural downlight
• Length: 180 mm
• Power Consumption: 12 W
• Luminous Flux: 600 lm
• Luminous Efficacy: 50 lm/W
• Beam Angle: Wide beam
• Driver Type: ON/OFF
• Diffuser: Structural opal (opalised plastic)
• UGR: 21
• CRI: >80 (830, 840)
• Colour Temperature: 3000 K or 4000 K
• MacAdam Step: SDCM 3
• Housing Material: Powder-coated steel
• Finish Options: White, Grey, Black, Anthracite
• Protection Rating: IP44
• Impact Resistance: IK04
• Class of Protection: Class I
• Net Weight: 1 kg
• Emergency Module: Optional
• Motion Sensor: Optional
• Lifespan: 60,000 h (LLMF 70%)
• Certifications: CE, HACCP+

Why Specify SD1018?

Because when space is limited, but expectations aren’t, SD1018 delivers clean lines, soft output, and architectural sharpness in one sealed, surface-ready unit.

DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.
