SD1020 | Multi-Size Surface-Mount Rectangular Downlight with Anti-Glare Optics and Defined Dimensions

SD1020 is a modular surface-mounted rectangular downlight range designed to scale across projects of any size. Offered in three wattage and housing formats - Small (10W), Medium (20W), and Large (30W), each fitting retains the same glare-minimising performance and crisp architectural form. Ideal for consistent design language across mixed-use spaces.

🧩 Key Features:

• Architectural Rectangular Housing: Slim, surface-mounted body in three physical sizes

• Defined Wattage + Dimensions:

  • SD1004 - Small (10W) - 118 × 118 × 100mm

  • SD1005 - Medium (20W) - 160 × 160 × 100mm

  • SD1020 -  Large (30W) - 200 × 200 × 100mm

• Recessed Anti-Glare Optics: Minimises eye strain and unwanted reflections

• Beam Angle Options: 15°, 24°, or 38° depending on task or wash requirements

• Selectable Colour Temperatures: 2700K / 3000K / 3500K / 4000K

• Efficient Output: Up to 150lm/W

• Durable Aluminium Build: Thermal management baked into the form factor

🏢 Ideal Applications:
Office ceilings, meeting rooms, education corridors, hotel reception areas, and anywhere requiring elegant surface mounting with the ability to scale output and size.

📐 Technical Summary:

• Power Options: 10W / 20W / 30W

• Dimensions:

  • Small: 118 × 118 × 100mm

  • Medium: 160 × 160 × 100mm

  • Large: 200 × 200 × 100mm

• Input Voltage: AC220-240V

• CRI: ≥90

• CCT Options: 2700K / 3000K / 3500K / 4000K

• Beam Angles: 15°, 24°, 38°

• Luminous Efficacy: Up to150lm/W

• Power Factor: ≥0.9

• Material: Aluminium

• Mounting: Surface

• Warranty: 5 years

✅ Why Specify SD1020?
Because lighting should flex with your space, not force you to compromise. SD1020 gives you three sizes, multiple wattages, clean architectural design, and glare control in one consistent product family.
