SM1008

SM1008

SUSPENDED

The independently installed luminaire features an asymmetric light distribution specifically designed for LED technology. This luminaire serves as an excellent solution for illuminating shop shelves, blackboards, and any surfaces that require additional lighting. Its innovative design allows for targeted illumination, enhancing visibility and drawing attention to displayed items or important information. Perfect for retail environments and educational settings, this luminaire combines functionality with efficiency, ensuring that your lighting needs are met with precision.

  • Materials: Housing made of electrostatically painted steel sheets (white color), asymmetric reflector of polished and anodized aluminum.
  • Installation:

SM1008 | Surface-Mounted Asymmetrical LED Linear Luminaire for Wall Illumination

The SM1008 is a surface-mounted asymmetrical LED luminaire designed for efficient vertical surface lighting.

Its sleek profile and optimised light distribution make it an ideal solution for projects requiring feature wall highlighting without complex installation requirements.

🔍 Key Features:

  • Asymmetrical Light Output: Engineered for precise wall washing and accent lighting, enhancing vertical architectural features.​
  • High Luminous Efficacy: Achieves up to 133 lm/W, ensuring bright, energy-efficient illumination.​
  • Slim Surface-Mounted Design: Clean, low-profile body for seamless surface installations in modern interiors.​
  • Durable Construction: Built with a powder-coated aluminum housing and opal PMMA diffuser for consistent performance and longevity.​
  • Flexible Driver Options: Available with ON/OFF or DALI dimming; optional emergency pack for additional safety.​
  • Certified Quality: CE-compliant, ensuring reliability, performance, and project compliance.​

🏢 Ideal Applications:

  • Retail feature walls and shop displays
  • Museums and exhibition spaces
  • Hospitality and hotel reception zones
  • Commercial office corridors
  • Architectural public areas​

📐SM1008 Technical Specifications:

  • Power Consumption: 17W / 34W / 51W​
  • Luminous Flux: 2,300 lm / 4,600 lm / 6,900 lm​
  • Luminous Efficacy: Up to 133 lm/W​
  • Colour Temperature: 3000K or 4000K​
  • CRI: >80​
  • MacAdam SDCM: 3​
  • UGR: <19 (depending on mounting height and wall distance)​
  • Driver Options: ON/OFF, DALI​
  • Emergency Module: Optional (1h emergency version available)​
  • Protection Rating: IP20​
  • Impact Resistance: IK04​
  • Class of Protection: Class I​
  • Housing Material: Aluminum (powder-coated)​
  • Diffuser Material: PMMA (opal)​
  • Mounting Options: Surface-mounted (wall or ceiling)​
  • Dimensions: 595mm / 1175mm / 1455mm lengths available​
  • Weight: ~2.0–3.5 kg (depending on size)​

DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.

WATTAGE LUMEN LENGTH (L) WIDTH (W) HEIGHT (H)
17

1,600 llm

610 172 80
32
3,350 llm
1170 172 80
