• SC1026.
1 1

SM1010

SM1010

SUSPENDED

This luminaire is ideal for universal application in various office environments, including hallways, conference rooms, and computer rooms. Featuring an OPAL diffuser, it ensures a soft and uniform light distribution for improved visibility. The option for DALI lighting control is available upon request, providing enhanced versatility in managing your lighting needs. Designed for T24 ceilings, it can also be adapted for T15 ceilings upon request, making it a practical choice for any modern workspace.

  • Materials: Powder painted steel sheet body (standard colour: white). OPAL, microprismatic (MPRM) diffusers
  • Installation:

SM1010 | Surface-Mounted Modular LED Luminaire for Commercial Interiors

The SM1010 is a surface-mounted modular LED luminaire offering a clean, modern alternative to recessed grid lighting.

Designed for direct ceiling installation, it combines high luminous efficacy with robust construction, making it ideal for a wide range of commercial and public sector environments.

🔍 Key Features:

  • Modular Surface Design: Offers the aesthetic of traditional grid ceiling panels without the need for ceiling cavities.​
  • High Luminous Efficacy: Delivers up to 125 lm/W, providing bright, energy-efficient illumination across large spaces.​
  • Durable Construction: Features a robust steel housing with a powder-coated finish and a high-quality opal PMMA diffuser for uniform light distribution.​
  • Easy Installation: Designed for quick surface mounting directly onto solid ceilings or slab soffits, reducing installation complexity.​
  • Driver Flexibility: Available with ON/OFF or DALI dimmable drivers; optional emergency module enhances versatility for safety-critical installations.​
  • Certified Quality: CE-compliant, ensuring reliable performance and compliance with modern building standards.​

🏢 Ideal Applications:

  • Offices and co-working spaces
  • Retail spaces and shopping centres
  • Educational institutions
  • Healthcare facilities
  • Hospitality and public sector buildings​

📐 Technical Specifications:

  • Power Consumption: 34W​
  • Luminous Flux: 4,250 lm​
  • Luminous Efficacy: Up to 125 lm/W​
  • Colour Temperature: 3000K or 4000K​
  • CRI: >80​
  • MacAdam SDCM: 3​
  • UGR: <22 (depending on ceiling height and installation layout)​
  • Driver Options: ON/OFF, DALI​
  • Emergency Module: Optional (1h emergency backup available)​
  • Protection Rating: IP40​
  • Impact Resistance: IK04​
  • Class of Protection: Class I​
  • Housing Material: Steel (powder-coated)​
  • Diffuser Material: PMMA (opal)​
  • Mounting Options: Surface-mounted (direct ceiling fixing)​
  • Dimensions: 595mm x 595mm​
  • Weight: ~3.5 kg​

⚡ Quick takeaway:

  • The SM1010 is your go-to solution when recessed installation isn’t practical, but a clean, modular look is still required.
  • Perfect for refurb projects, slab ceiling offices, and anywhere you want modern lighting without invasive ceiling work. 🎯

DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.

WATTAGE LUMEN LENGTH (L) WIDTH (W) HEIGHT (H)
38

4,370 llm

 595 595 75
CONTINUE TO CUSTOMISE

KEY HIGHLIGHTS

  • Energy Efficiency

    We are commited to utilising the most energy-efficient lighting solutions on the market. Sustainable choices for your business or private use.

  • Long Life Electronics

    Recent advancements make the switch to LED a long-lasting investment. Embrace the durability and energy-saving features for an eco-friendly choice.

  • Certified Quality System

    Manufactured and audited to ISO9001:2015 by TÜV SÜD Rheinland.
