SM1013

SM1013 | Surface-Mounted Linear CCT-Adjustable LED Batten for Commercial & Utility Spaces

SM1013 is a high-efficiency LED surface batten, offering exceptional light uniformity, selectable colour temperature, and an ultra-durable construction ideal for commercial and functional spaces. Designed to replace traditional fluorescents, it delivers instant savings with a professional finish.

🧩 Key Features:

• Selectable Power and CCT: Choose between 21W/37W, 32W/56W, or 40W/63W outputs and toggle between 3000K, 4000K, or 6000K via internal dip switches

• Efficient Performance: Delivers up to 132lm/W for high-impact illumination

• Diffused Optics: Opal diffuser ensures a soft, uniform light spread without hotspots

• Robust Housing: Powder-coated steel body with polycarbonate diffuser built for longevity

• Plug-and-Play: Quick and easy installation for retrofit or new build scenarios

• High Colour Fidelity: CRI 80+ for accurate colour rendering

• TP(a) Rated: Compliant for public and commercial installations requiring fire-safe materials

• Integrated Driver: Non-dimmable internal driver designed for simple, no-fuss connectivity

• Switchable Technology: One luminaire, multiple configurations reduce inventory, boost flexibility

• 5-Year Warranty: Backed by manufacturer's extended support for long-term reliability

🏢 Ideal Applications:
Offices, corridors, warehouses, utility areas, education, commercial units, residential common areas, and retail back-of-house.

📐 Technical Specifications:

• Mounting: Surface-mounted

• Length: 1200(L), 1500(L), 1800(L)

• Power Settings: 21W/37W, 32W/56W, 40W/63W (Switchable)

• Luminous Flux: 7,772 - 8,316lm

• Efficacy: Up to 132 lm/W

• CCT Options: 3000K, 4000K, 6000K (Switchable)

• CRI: >80

• Diffuser: Opal polycarbonate

• IP Rating: IP20

• Housing Material: White powder-coated steel

• Beam Angle: 120°

• Driver: Integrated, non-dimmable

• Rated Life: 75,000 hours

• Warranty: 5 years

• TP Rating: TP(a)

💡 Why Specify SM1013?
Because smart lighting doesn't need to be complicated. SM1013 blends form and function, delivering selectable brightness, adaptive colour temperature, and a hassle-free install, all wrapped in a robust commercial housing. It's the smart choice for contractors, specifiers, and clients demanding versatility without compromise.
