TS1021

TS1021 | Track-Mounted Tubular LED Downlight with Precision Beam Control

The TS1021 is a cylindrical LED downlight engineered for 3-circuit track systems. With selectable beam angles and compact architectural form, it delivers high-efficiency illumination for retail, hospitality, and gallery settings where directional light and layout flexibility are key.

🛠 Key Features:

• Track-Mounted Flexibility: Compatible with 3-circuit track systems for adjustable layout and positioning
• Cylindrical Form Factor: Clean tubular housing blends into modern interiors
• Selectable Beam Angles: 30°, 50°, or 70° beam spreads for narrow, medium, or wide flood applications
• High Efficiency: Up to 2,640 lm output and 98 lm/W for low-energy performance
• Driver Options: ON/OFF or DALI control available
• Finishes: Anthracite, white, black, grey — or match any RAL for custom spec
• Optional Modules: Emergency and motion sensor versions available

🛍 Ideal Applications:

Retail stores, art galleries, display environments, receptions, design studios, and modern commercial interiors where beam focus and adjustable layout are essential

📐 Technical Specifications:

• Mounting Type: Track-mounted (3-circuit)
• Power Consumption: 15 W, 21 W, 29 W
• Luminous Flux: 1,330 – 2,640 lm
• Luminous Efficacy: 82 – 98 lm/W
• Beam Angles: 30°, 50°, 70°
• Colour Temperature: 3000 K, 4000 K
• CRI: >80 (830 / 840)
• UGR: 18–27
• Driver Options: ON/OFF, DALI
• Housing Material: Powder-coated aluminium
• Diffuser: Transparent
• Protection Rating: IP20
• Impact Resistance: IK10
• Class of Protection: Class I
• Operating Temp Range: -20°C to +35°C
• Weight: 0.6 – 0.8 kg
• Finish Options: Anthracite, White (RAL 9003), Black (RAL 9005), Grey, Custom RAL
• Certifications: CE, HACCP+

Why Specify TS1021?

Because retail and gallery lighting shouldn’t just light — it should flex, focus, and perform. TS1021 gives you the versatility of track, the precision of beam control, and the minimalist aesthetic of architectural downlighting.

DIMENSIONS
