EXTERIOR FLOOD

The XF1001 is a floodlight designed with LED light sources, featuring excellent optical characteristics. It is ideal for illuminating a variety of spaces, including sports fields, swimming pools, car parks, and manoeuvring areas. Its robust design ensures effective and reliable lighting, enhancing visibility and safety in both recreational and commercial settings. The XF1001 combines functionality with energy efficiency, making it an outstanding choice for diverse outdoor applications.

  • Materials: Body of die cast aluminium painted with thermosetting paint. Tempered glass.
  • Installation: Wall, floor, installation bracket included

XF1001 | High-Performance Architectural LED Floodlight

The XF1001 is a robust and versatile LED floodlight designed for demanding architectural and industrial applications.

Its sleek die-cast aluminium housing and high ingress protection rating make it ideal for both indoor and outdoor environments where durability and performance are paramount.​

🔍 Key Features:

  • Durable Construction: Crafted from die-cast aluminium with a tempered glass diffuser, ensuring longevity and resistance to environmental factors.​

  • High Ingress Protection: IP65-rated for protection against dust and water ingress, suitable for challenging environments.​

  • Impact Resistance: IK10-rated, offering high resistance to mechanical impacts.​

  • Versatile Mounting Options: Designed for wall, floor, and post mounting, providing flexibility in installation.​

  • Energy-Efficient Performance: Offers a power range of 25–206W, delivering luminous flux between 3,150–30,100 lm with an efficacy of up to 162 lm/W.​

  • Advanced Optical Systems: Equipped with LNS diffusers and various beam angles (e.g., 25°, 135°x85°) for tailored light distribution.​

  • Smart Control Compatibility: Available with ON/OFF or DALI drivers, facilitating integration with modern lighting control systems.​

  • Color Temperature Options: Available in 3000K and 4000K, catering to different ambiance requirements.​

  • Customization: Standard finishes include white, grey, and anthracite, with the option for custom RAL colours to match specific design needs.​

🏢 Ideal Applications:

Perfect for illuminating sports fields, swimming pools, car parks, manoeuvring areas, building facades, and other architectural settings where both form and function are paramount.​

📐 Technical Specifications:

  • Power Consumption: 25–206W​

  • Luminous Flux: 3,150–30,100 lm​

  • Efficacy: Up to 162 lm/W​

  • Colour Temperatures: 3000K / 4000K​

  • CRI: ≥80​

  • Beam Angles: Various options including 25°, 135°x85°​

  • Driver Options: ON/OFF, DALI​

  • IP Rating: IP65​

  • Impact Resistance: IK10​

  • Operating Temperature: -25°C to +40°C​

  • Finish Options: White, Grey, Anthracite, Custom RAL​

Elevate your architectural lighting design with the XF1001, where form meets function in perfect harmony.


DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.

WATTAGE

(W)

LUMINIAIRE

(llm/W)

DIAMETER

(Ø)

HEIGHT

(H)
25
4050 llm
 275 70
52
7780 llm
 275 70
122
18,510 llm
 385 70
170
23,770 llm
 425 70
206
30,100 llm
 425 70
CONTINUE TO CUSTOMISE

KEY HIGHLIGHTS

  • Energy Efficiency

    We are commited to utilising the most energy-efficient lighting solutions on the market. Sustainable choices for your business or private use.

  • Long Life Electronics

    Recent advancements make the switch to LED a long-lasting investment. Embrace the durability and energy-saving features for an eco-friendly choice.

  • Certified Quality System

    Manufactured and audited to ISO9001:2015 by TÜV SÜD Rheinland.
