XH1007 | IP67/IK10 Micro Recessed Handrail Light with Asymmetric Beam

XH1007 is a high-performance recessed LED handrail luminaire designed for minimal visual impact with maximum directional illumination. Engineered with a 1.6W asymmetric beam, this compact fixture is perfect for enhancing safety and ambience on stairways, pathways, and architectural railings - all while disappearing seamlessly into the structure.

🧩 Key Features:

• Recessed Handrail Lighting: Fully integrated into the handrail surface for a clean, tamper-resistant finish

• Asymmetric Light Distribution: Targets the walking plane without glare or spill, ideal for accessibility and compliance

• IP67 / IK10 Rated: Built for extreme durability in both indoor and outdoor environments

• Low Wattage, High Impact: Energy-efficient 1.6W output that delivers sharp illumination with minimal consumption

• Glare-Free Design: Specialised optical lensing ensures user comfort and effective beam direction

• Minimalist Form Factor: Slimline profile suited to architectural stainless steel and aluminium handrail systems

• Customisable Finishes: Multiple body colours and beam angles available upon request

🏢 Ideal Applications:

Stadiums, transport hubs, civic centres, university campuses, footbridges, parks, and any application demanding unobtrusive but robust pathway lighting embedded into handrails.

📐 Technical Specifications:

• Mounting Type: Recessed into round or square handrail profiles

• Power: 1.6W

• Luminous Output: ~90 lm (nominal)

• Protection Rating: IP67 (dust-tight & submersible)

• Impact Resistance: IK10 (anti-vandal, suitable for public use)

• Material: CNC-machined aluminium housing

• Finish: Standard silver/black anodised (custom colours on request)

• Beam Angles: Asymmetric

• Colour Temperatures: 2700K / 3000K / 4000K

• Input Voltage: 24V DC

• Control Options: ON/OFF, DALI2, CASAMBI

🧠 Why Specify XH1007?

Because precision matters, especially in public environments where lighting must enhance safety without disrupting design intent. XH1007 delivers rugged reliability, sharp asymmetric optics, and seamless integration into modern handrails, all in a compact body that blends in and performs brilliantly.
