XH1009

XH1009 | Asymmetric Recessed Handrail LED Light, Ultra-Slim, Discreet, IP67 Rated

XH1009 is a sleek, ultra-compact handrail-integrated LED marker light designed for elegant illumination with minimal visual intrusion. With an asymmetric light beam, 1.2W energy-efficient output, and IP67 protection, it delivers precision lighting to stairs and walkways while seamlessly disappearing into stainless steel handrail structures.

🧩 Key Features:

• Ultra-Slim Recessed Design: Tailored for flush integration into Ø42/48mm stainless steel handrails.

• Asymmetric Beam Angle: Engineered optical output focuses light exactly where it’s needed, enhancing safety without glare.

• High Durability: IP67 ingress protection and IK10 impact resistance for enduring outdoor and public-use conditions.

• Efficient Output: 1.2W power consumption with 3000K, 3500K, 4000K colour temperature options for welcoming pathways.

• Robust Construction: CNC-machined stainless steel body and anti-UV PMMA lens for longevity and visual quality.

• Versatile Driver Compatibility: Operates with constant current drivers at 350mA (1.2W) or 500mA (1.8W) depending on intensity requirement.

🏢 Ideal Applications:

Public staircases, pedestrian bridges, metro and transport hubs, hotel handrails, and modern commercial walkways where discrete yet effective illumination is required.

📐 Technical Summary:

• Mounting: Recessed into stainless steel handrails (Ø42/48mm)

• Power: 1.2W @ 350mA / 1.8W @ 500mA

• Luminous Output: ~80 lm

• Colour Temperature: 3000K, 3500K, 4000K

• Beam Angle: Asymmetric

• Material: CNC-milled stainless steel body

• Diffuser: PMMA, UV-resistant

• Ingress Protection: IP67

• Impact Resistance: IK10

• Cut-out Hole: Ø18mm

• Lifetime: >60,000h (L80B10)

• Compliance: CE certified


• Input Voltage: 24V DC

• Driver Options: ON/OFF, DALI2, CASAMBI

✅ Why Specify XH1009?

Because when lighting needs to perform without being seen, the XH1009 is the go-to detail. It’s ultra-slim, brutal on ingress and impact, and elegant in execution. For specifiers needing recessed safety lighting in high-traffic environments—without sacrificing design integrity, XH1009 delivers form, function, and finesse in one tight footprint.
