DL1127

DL1127 | Twin-Axis Adjustable Recessed LED Downlight for Directional Commercial Lighting

DL1127 is a precision-engineered recessed downlight designed for targeted lighting within modular and plasterboard ceilings. With dual-axis adjustable heads and clean architectural styling, this fixture is ideal for accent and general lighting in commercial environments that demand both flexibility and subtlety.

🧩 Key Features:

• Fully Adjustable Head(s): Independent twin-axis rotation for directional accent lighting
• Modular Ceiling Ready: Compatible with plasterboard and grid ceiling systems
• Compact Sizes: Available in 116 mm and 203 mm formats for discrete recessed integration
• Clean Output: 600 – 1120 lm with 8.5 – 15 W power draw, delivering up to 75 lm/W
• Precision Beam: 35° beam angle with high-gloss reflector for controlled focus
• Driver Options: ON/OFF and DALI configurations available
• Finish Variants: Offered in white, grey, and black — suitable for clean commercial aesthetics

🏢 Ideal Applications:

Retail displays, office reception zones, corridors, stairwells, and meeting rooms where adjustable beam direction and architectural integration are key.

📐 Technical Specifications:

• Mounting Type: Recessed (modular & plasterboard ceilings)
• Form Factor: Adjustable downlight with independent spotlighting
• Length Options: 116 mm, 203 mm
• Power Range: 8.5 – 15 W
• Luminous Flux: 600 – 1120 lm
• Luminous Efficacy: 71 – 75 lm/W
• Beam Angle: 35°
• Driver Options: ON/OFF, DALI
• CRI: >80 (830, 840)
• Colour Temperature: 3000 K or 4000 K
• Housing Material: Powder-coated aluminium with steel body
• Finish Options: White, Grey, Black
• Protection Rating: IP20 (top & bottom)
• Impact Resistance: IK04
• Class of Protection: Class I, Class II
• Net Weight: 0.7 – 1.2 kg
• Operating Temperature: 0 to +35°C
• Emergency Module: Optional
• Motion Sensor: Optional
• Flicker: ≤3%
• Lifespan: 60,000 h (LLMF 85%)
• Certifications: CE, HACCP+, EAC

Why Specify DL1127?

Because lighting isn’t always about brightness — sometimes it’s about control. DL1127 gives you pinpoint directional performance in a trimless, architectural package built for commercial ceilings.

DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.
