DL1129 | Compact IP65 Recessed LED Downlight for Bathrooms, Corridors & Utility Areas

DL1129 is a compact, recessed LED downlight engineered for humid environments and utility areas. With a faceted aluminium reflector, IP65 front-facing protection, and efficient 1240 lm output, it offers reliable accent or general lighting for functional spaces without sacrificing quality or durability.

🧩 Key Features:

  • IP65 Front Protection: Water and dust-resistant face — ideal for washrooms, stairwells, and damp zones
  • Compact Form: Slimline 72 mm cut-out for unobtrusive ceiling integration
  • Optimised Output: 1240 lm from just 14 W with an efficacy of 89 lm/W
  • Clear Optics: 40° beam angle with faceted aluminium reflector and tempered glass cover
  • Control Options: DALI and ON/OFF driver options available
  • Colour Temperature Options: 3000 K or 4000 K (CRI 80, MacAdam 3)
  • RAL Finishes: Available in white, grey, black, anthracite and custom RALs on request
🏢 Ideal Applications:

Bathrooms, changing rooms, social spaces, corridors, stairwells, cloakrooms, technical rooms, and utility areas requiring recessed IP65 lighting.

📐 Technical Specifications:

  • Mounting Type: Recessed (plasterboard ceilings)
  • Cut-Out Size: Ø72 mm
  • Power Consumption: 14 W
  • Luminous Flux: 1240 lm
  • Luminous Efficacy: 89 lm/W
  • Beam Angle: 40°
  • Driver Options: ON/OFF, DALI
  • Diffuser: Transparent tempered glass (LNS)
  • CRI: >80 (830, 840)
  • Colour Temperature: 3000 K or 4000 K
  • MacAdam Step: SDCM 3
  • Housing Material: Powder-coated aluminium ring
  • Finish Options: White, Grey, Black, Anthracite, Anthracite RAL7016, or any RAL
  • Protection Rating: IP65 (bottom) / IP20 (top)
  • Impact Resistance: IK04
  • Class of Protection: Class I
  • Net Weight: 0.2 kg
  • Operating Temperature: -15 to +40°C
  • Power Factor: 0.96
  • Emergency Module: Optional
  • Motion Sensor: Optional
  • Lifespan: 60,000 h (LLMF 80%)
  • Certifications: CE, HACCP+, EAC
Why Specify DL1129?

Because even utility lighting deserves quality. DL1129 delivers dependable, glare-controlled light in a compact IP65-rated form, fit for bathrooms, back-of-house, and beyond.

DIMENSIONS

NOTE: All dimensions are measured in millimeters (mm). Lumens are delivered and based on 4000K. Changing some options may affect the lumen value - please contact sales if you are unsure.

WATTAGE LUMEN DIAMTER (Ø) HIEGHT (H) CUT-OUT (Ø)
14

1,240 llm

 90 90 65
CONTINUE TO CUSTOMISE

KEY HIGHLIGHTS

  • Energy Efficiency

    We are commited to utilising the most energy-efficient lighting solutions on the market. Sustainable choices for your business or private use.

  • Long Life Electronics

    Recent advancements make the switch to LED a long-lasting investment. Embrace the durability and energy-saving features for an eco-friendly choice.

  • Certified Quality System

    Manufactured and audited to ISO9001:2015 by TÜV SÜD Rheinland.
